APPENDIX A ELECTRICAL CHARACTERISTICS
This appendix contains electrical parameters for the MC68HC11F1 microcontroller.
Table A-1 Maximum Ratings
Rating
Symbol
Value
Unit
V
Supply Voltage
Input Voltage
V
– 0.3 to + 7.0
– 0.3 to + 7.0
DD
V
V
in
A
Operating Temperature Range
MC68HC11F1
T
T to T
°C
L
H
0 to + 70
MC68HC11F1C
MC68HC11F1V
MC68HC11F1M
– 40 to + 85
– 40 to + 105
– 40 to + 125
Storage Temperature Range
T
– 55 to + 150
25
°C
stg
Current Drain per Pin*
I
mA
D
Excluding V , V , AV , V , and V
RL
DD
SS
DD
RH
*One pin at a time, observing maximum power dissipation limits.
Internal circuitry protects the inputs against damage caused by high static voltages or
electric fields; however, normal precautions are necessary to avoid application of any
voltage higher than maximum-rated voltages to this high-impedance circuit. Extended
operation at the maximum ratings can adversely affect device reliability. Tying unused
inputs to an appropriate logic voltage level (either GND or V ) enhances reliability of
DD
operation.
ELECTRICAL CHARACTERISTICS
TECHNICAL DATA
A-1
