Central Processor Unit (CPU)
7.3 CPU Registers
Figure 7-1 shows the five CPU registers. CPU registers are not part of the memory
map.
7
0
0
0
0
ACCUMULATOR (A)
15
15
15
H
X
INDEX REGISTER (H:X)
STACK POINTER (SP)
PROGRAM COUNTER (PC)
CONDITION CODE REGISTER (CCR)
7
0
V
1
1
H
I
N
Z
C
CARRY/BORROW FLAG
ZERO FLAG
NEGATIVE FLAG
INTERRUPT MASK
HALF-CARRY FLAG
TWO’S COMPLEMENT OVERFLOW FLAG
Figure 7-1. CPU Registers
7.3.1 Accumulator
The accumulator is a general-purpose 8-bit register. The CPU uses the
accumulator to hold operands and the results of arithmetic/logic operations.
Bit 7
6
5
4
3
2
1
Bit 0
Read:
Write:
Reset:
Unaffected by reset
Figure 7-2. Accumulator (A)
Data Sheet
88
MC68HC908MR32 • MC68HC908MR16 — Rev. 6.0
Central Processor Unit (CPU) MOTOROLA
