Data Sheet — MC68HC908MR32 • MC68HC908MR16
Section 20. Ordering Information and Mechanical Specifications
20.1 Introduction
This section provides ordering information for the MC68HC908MR16 and
MC68HC908MR32 along with the dimensions for:
•
•
64-lead plastic quad flat pack (QFP)
56-pin shrink dual in-line package (SDIP)
The following figures show the latest package drawings at the time of this
publication. To make sure that you have the latest package specifications, contact
your local Motorola Sales Office.
20.2 Order Numbers
Table 20-1. Order Numbers
Operating
Temperature Range
MC Order Number(1)
68HC908MR16CFU
68HC908MR16VFU
–40°C to +85°C
–40°C to +105°C
68HC908MR16CB
68HC908MR16VB
–40°C to +85°C
–40°C to +105°C
68HC908MR32CFU
68HC908MR32VFU
–40°C to +85°C
–40°C to +105°C
68HC908MR32CB
68HC908MR32VB
–40°C to +85°C
–40°C to +105°C
1. FU = quad flat pack
B = shrink dual in-line package
M C 6 8 H C 9 0 8 M R 3 2 X X X
PACKAGE DESIGNATOR
FAMILY
TEMPERATURE RANGE
Figure 20-1. Device Numbering System
MC68HC908MR32 • MC68HC908MR16 — Rev. 6.0
MOTOROLA Ordering Information and Mechanical Specifications
Data Sheet
301
