Serial Communications Interface (SCI)
17.5 Functional Description
Figure 17-1 shows the structure of the SCI module. The SCI allows
full-duplex, asynchronous, NRZ serial communication between the MCU
and remote devices, including other MCUs. The transmitter and receiver
of the SCI operate independently, although they use the same baud rate
generator. During normal operation, the CPU monitors the status of the
SCI, writes the data to be transmitted, and processes received data.
INTERNAL BUS
SCI DATA
REGISTER
SCI DATA
REGISTER
RECEIVE
SHIFT REGISTER
TRANSMIT
SHIFT REGISTER
TxD
RxD
TXINV
SCTIE
R8
T8
TCIE
SCRIE
ILIE
TE
SCTE
TC
RE
RWU
SBK
SCRF
IDLE
OR
NF
FE
PE
ORIE
NEIE
FEIE
PEIE
LOOPS
ENSCI
LOOPS
RECEIVE
CONTROL
FLAG
CONTROL
TRANSMIT
CONTROL
WAKEUP
CONTROL
M
BKF
RPF
ENSCI
WAKE
ILTY
PEN
PTY
PRE-
BAUD RATE
÷ 4
CGMXCLK
SCALER GENERATOR
DATA SELECTION
CONTROL
÷ 16
Figure 17-1. SCI Module Block Diagram
Technical Data
MC68HC908AS60 — Rev. 1.0
