Parallel Host Interface (HDI08)
Table 2-9 Host Interface (continued)
State During
Signal Name
Type
Signal Description
Reset
HCS
Input
GPIO
Host Chip Select—When HDI08 is programmed to interface a
Disconnected nonmultiplexed host bus and the HI function is selected, this signal is the host
chip select (HCS) input. The polarity of the chip select is programmable, but
is configured active-low (HCS) after reset.
HA10
PB13
Input
Host Address 10—When HDI08 is programmed to interface a multiplexed
host bus and the HI function is selected, this signal is line 10 of the host
address (HA10) input bus.
Input, Output, or
Disconnected
Port B 13—When the HDI08 is configured as GPIO, this signal is individually
programmed as input, output, or internally disconnected.
The default state after reset for this signal is GPIO disconnected.
This input is 3.3V tolerant.
HOREQ/
HOREQ
Output
Output
GPIO
Host Request—When HDI08 is programmed to interface a single host
Disconnected request host bus and the HI function is selected, this signal is the host request
(HOREQ) output. The polarity of the host request is programmable, but is
configured as active-low (HOREQ) following reset. The host request may be
programmed as a driven or open-drain output.
HTRQ/
HTRQ
Transmit Host Request—When HDI08 is programmed to interface a double
host request host bus and the HI function is selected, this signal is the transmit
host request (HTRQ) output. The polarity of the host request is
programmable, but is configured as active-low (HTRQ) following reset. The
host request may be programmed as a driven or open-drain output.
PB14
Input, Output, or
Disconnected
Port B 14—When the HDI08 is configured as GPIO, this signal is individually
programmed as input, output, or internally disconnected.
The default state after reset for this signal is GPIO disconnected.
This input is 3.3V tolerant.
HACK/
HACK
Input
GPIO
Host Acknowledge—When HDI08 is programmed to interface a single host
Disconnected request host bus and the HI function is selected, this signal is the host
acknowledge (HACK) Schmitt-trigger input. The polarity of the host
acknowledge is programmable, but is configured as active-low (HACK) after
reset.
HRRQ/
HRRQ
Output
Receive Host Request—When HDI08 is programmed to interface a double
host request host bus and the HI function is selected, this signal is the receive
host request (HRRQ) output. The polarity of the host request is
programmable, but is configured as active-low (HRRQ) after reset. The host
request may be programmed as a driven or open-drain output.
PB15
Input, Output, or
Disconnected
Port B 15—When the HDI08 is configured as GPIO, this signal is individually
programmed as input, output, or internally disconnected.
The default state after reset for this signal is GPIO disconnected.
This input is 3.3V tolerant.
