User Guide
Featured documentacion:
• MEDUSBAPIRM—Medical Applications USB Stack API Reference
• MEDCONLIBAPIRM—USB Device API Reference
• MEDUSBUG—Medical Applications USB Stack User Guide
• MEDCONLIBUG—Medical Connectivity Library Users Guide
• MDCLUSBSFTWRFS—Medical Applications USB Stack Fact Sheet
USB hardware connections:
Figure 24. MC9S08JS16 connection and USB connector
13 User Guide
After the glucometer and blood pressure monitor are developed, it is time to test the system. Chapter 5. Blood Pressure Monitor
explains how to interconnect these devices and this section explains how to use the system. First, it is important to localize a
connection for the battery, motor, valve, glucose connector, and pressure sensor. Connection of a 9V power supply to the system
is required.
NOTE
Without a J7 jumper the system remains off. Turn the system on to start.
System:
Figure 25. Evaluation board
Implementing a Glucometer and Blood Pressure Monitor Medical Devices, Rev. 1, 4/2010
26
Freescale Semiconductor, Inc.
