* No interrupts are enabled, source (read) cycle. Increment source
* address, source size is long word, REQ is external burst request.
* Single-address mode, start the DMA transfers.
MOVE.W
#$1823,DMACCR1(A0)
***************************************************************************
END
***************************************************************************
Example 2: Internal Request Generation, Memory to Memory Transfers.
***************************************************************************
* MC68340 basic DMA channel register initialization example code.
* This code is used to initialize the 68340's internal DMA channel
* registers, providing basic functions for operation.
* The code sets up channel 1 for internal request generation
* memory to memory transfers.
***************************************************************************
***************************************************************************
* SIM40 equates
***************************************************************************
MBAR
EQU $0003FF00 Address of SIM40 Module Base Address Reg.
MODBASE EQU $FFFFF000 SIM40 MBAR address value
***************************************************************************
* DMA Channel 1 equates
DMACH1
DMAMCR1 EQU $0
EQU $780
Offset from MBAR for channel 1 regs
MCR for channel 1
* Channel 1 register offsets from channel 1 base address
DMAINT1
EQU $4
interrupt register channel 1
control register channel 1
status register channel 1
function code register channel 1
source address register channel 1
destination address register channel 1
byte transfer count register channel 1
source address
DMACCR1 EQU $8
DMACSR1 EQU $A
DMAFCR1 EQU $B
DMASAR1 EQU $C
DMADAR1 EQU $10
DMABTC1 EQU $14
SARADD
DARADD
EQU $6000
EQU $8000
destination address
NUMBYTE EQU $E
number of bytes to transfer
***************************************************************************
***************************************************************************
* Initialize DMA Channel 1
***************************************************************************
LEA MODBASE+DMACH1,A0 Pointer to channel 1
* Initialize DMA channel 1 MCR
6- 40
MC68340 USER’S MANUAL
MOTOROLA
