Freescale Semiconductor, Inc.
CPU CYCLE
S2
DMA READ
S4
CPU CYCLE
S2 S4
..
D
.........
M
.....
.
A READ
S0
S0
S4
S0
S0 S2
CLKOUT
A31–A0
FC3–FC0
SIZ1–SIZ0
AS
DS
R/W
D15–D0
DSACKx
DREQx
DACKx
DONEx
(OUTPUT)
NOTE:
1. To cause another DMA transfer, DREQx is asserted after DACKx is asserted and before
DACKx is negated.
2. DACKx and DONEx (DMA control signals) are asserted in the source (read) DMA cycle.
Figure 6-13. Fast Termination Option (Cycle Steal)
If the fast termination option is used with external burst request mode (Figure 6-14), an
extra DMA cycle may result on every burst transfer. Normally, DREQ≈ is negated when
DACK≈ is returned. In the burst mode with fast termination selected, a new cycle starts
even if DREQ≈ is negated simultaneously with DACK≈ assertion.
MOTOROLA
MC68340 USER’S MANUAL
6- 21
