R-T Curve
600
550
500
450
400
350
300
250
200
150
100
50
R-T Curve in 50℃ ~ 125℃
20
16
12
8
4
0
50
60
70
80
90
100
110
120
Temperature [℃]
0
-20 -10
0
10
20
30
40
50
60
70
80
90 100 110 120
Temperature TTH[℃]
Figure. 6. R-T Curve of The Built-in Thermistor
Bootstrap Diode Part
Symbol
Parameter
Conditions
Min. Typ. Max. Units
VF
trr
Forward Voltage
Reverse Recovery Time
IF = 0.1A, TC = 25°C
IF = 0.1A, TC = 25°C
-
-
2.5
80
-
-
V
ns
Built in Bootstrap Diode VF-IF Characteristic
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
TC=25℃
0
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15
VF [V]
Note:
6. Built in bootstrap diode includes around 15Ωresistance characteristic.
Figure 7. Built in Bootstrap Diode Characteristic
8
www.fairchildsemi.com
FNA41560/B2 Rev. C
