Document No.: FT_000288
FT232H SINGLE CHANNEL HI-SPEED USB TO MULTIPURPOSE UART/FIFO IC
Datasheet Version 1.8
Clearance No.: FTDI #199
MPSSE mode is enabled using the FT_SetBitMode D2xx driver command with a hex value of 0x02. A hex
value of 0x00 will reset the device. See application note AN135 – MPSSE Basics for more details and
examples.
The MPSSE command set is fully described in application note AN108 – Command Processor For
MPSSE and MCU Host Bus Emulation Modes
4.8.1 MPSSE Adaptive Clocking
The Adaptive Clock mode correlates the CLK signal with a return clock RTCK. This is a technique used by
ARM® processors.
The FT232H will assert the TCK line and wait for the RTCK to be returned from the target device to
GPIOL3 line before changing the TDO (data out line).
TDO
TCK
GPIOL3
RTCK
ARM CPU
FT2232H
Figure 4.15 Adaptive Clocking Interconnect
TDO changes on falling
edge of TCK
TDO
TCK
RTCK
Figure 4.16: Adaptive Clocking waveform.
Adaptive clocking is not enabled by default.
For further details on MPSSE adaptive clocking please refer to AN_108 Command Processor For
MPSSE and MCU Host Bus Emulation Modes
Copyright © 2012 Future Technology Devices International Limited
37
