Hardware
Pin signals
The following illustration shows the module mounting into the receptacle on the RS-232 interface
board.
Century Interconnect and Samtec manufacture the 2 x 10 pin 2 mm spacing receptacles on Digi
development boards. Several other manufacturers provide comparable mounting solutions; we
currently use the following receptacles:
n
Through-hole single-row receptacles: Samtec part number: MMS-110-01-L-SV (or equivalent)
n
Surface-mount double-row receptacles: Century Interconnect part number: CPRMSL20-D-0-1
(or equivalent)
n
Surface-mount single-row receptacles: Samtec part number: SMM-110-02-SM-S
Note We recommend that you print an outline of the module on the board to indicate the
correct orientation for mounting the module.
Pin signals
The following image shows the pin numbers; it shows the device's top sides, the shields are on the
bottom.
The following table shows the pin assignments for the through-hole device. In the table, low-asserted
signals have a horizontal line above signal name.
Pin
Name
Direction
Description
1
VCC
-
Power supply
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
20
