Operate in API mode
Frame descriptions
Modem Status - 0x8A
Description
This frame type is emitted in response to specific conditions. The status field of this frame indicates
the device behavior.
Format
The following table provides the contents of the frame. For details on frame structure, see API frame
specifications.
Frame
Field
Offset
Size
Description
0
8-bit Start
Indicates the start of an API frame.
Delimiter
1
3
16-bit Length
Number of bytes between the length and checksum.
Modem Status - 0x8A
8-bit Frame type
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
138
