Operate in API mode
Frame descriptions
Examples
Each example is written without escapes (AP = 1) and all bytes are represented in hex format. For
brevity, the start delimiter, length, and checksum fields have been excluded.
Set remote command parameter
Host set the NI string of a remote device to "Remote" using a Remote AT Command Request - 0x17.
The corresponding 0x97 Remote AT Command Response with a matching Frame ID is emitted as a
response:
7E 00 0F 97 27 00 13 A2 00 12 34 56 78 12 7E 4E 49 00 51
Frame
type
64-bit
Frame ID source
AT
command
Command
Status
Reserved
Command data
0x97
0x27
0x0013A200
12345678
0x127E
0x4E49
0x00
(omitted)
Unused
Response
Matches
request
"NI"
Success
Parameter
changes return
no data
Transmission failure
Host queued the the PAN ID change of a remote device using a Remote AT Command Request - 0x17.
Due to existing network congestion, the host will retry any failed attempts.
The corresponding 0x97 Remote AT Command Response with a matching Frame ID is emitted as a
response:
7E 00 0F 97 27 00 13 A2 00 12 34 56 78 FF FE 49 44 04 EA
Frame
type
64-bit
Frame ID source
AT
command
Command
Status
Command
data
Reserved
0x97
0x27
0x0013A200
12345678
0xFFFE
0x4944
0x04
(omitted)
Unused
Response
Matches
request
"ID"
Transmission
failure
Parameter
changes return
no data
Query remote command parameter
Query the temperature of a remote device—.
The corresponding 0x97 Remote AT Command Response with a matching Frame ID is emitted with the
temperature value as a response:
7E 00 11 97 27 00 13 A2 00 12 34 56 78 FF FE 54 50 00 00 2F A8
