Operate in API mode
Frame descriptions
Set local command parameter
Host set the NI string of the local device to "End Device" using a 0x08 request frame.
The corresponding Local AT Command Response - 0x88 with a matching Frame ID is emitted as a
response:
7E 00 05 88 01 4E 49 00 DF
Frame
type
AT
command
Command
Status
Frame ID
Command data
0x88
0xA1
0x4E49
0x00
(omitted)
Response
Matches
request
"NI"
Success
Parameter changes return no
data
Query local command parameter
Host queries the temperature of the local device—TP command—using a 0x08 request frame.
The corresponding Local AT Command Response - 0x88 with a matching Frame ID is emitted with the
temperature value as a response:
7E 00 07 88 01 54 50 00 FF FE D5
Frame type
0x88
Frame ID
0x17
AT command
0x5450
Command Status
0x00
Command data
0xFFFE
Response
Matches request
"TP"
Success
-2 °C
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
134
