7 Detailed Description
7.1 Overview
The TLV900x series is a family of low-power, rail-to-rail input and output op amps. These devices operate from
1.8 V to 5.5 V, are unity-gain stable, and are designed for a wide range of general-purpose applications. The
input common-mode voltage range includes both rails and allows the TLV900x series to be used in virtually any
single-supply application. Rail-to-rail input and output swing significantly increases dynamic range, especially in
low-supply applications, and makes them suitable for driving sampling analog-to-digital converters (ADCs).
7.2 Functional Block Diagram
V+
Reference
Current
VIN+
VIN–
VBIAS1
Class AB
Control
Circuitry
VO
VBIAS2
V–
(Ground)
