Figure 20. Alternate CE# Controlled Write Operation Timings
PA for Program
SA for Sector Erase
0x555 for Chip Erase
0x555 for Program
0x2AA for Erase
Addresses
VA
tWC
tAS
tAH
WE#
OE#
CE#
Data
tWH
tGHEL
tCP
tCPH
tCWHWH1 / tCWHWH2 / tCWHWH3
tWS
tBUSY
tDS
tDH
Status
DOUT
PD for Program
0x30 for Sector Erase
0x10 for Chip Erase
0xA0 for Program
0x55 for Erase
RY/BY#
tRH
Reset#
Notes:
PA = address of the memory location to be programmed.
PD = data to be programmed at byte address.
VA = Valid Address for reading program or erase status
Dout = array data read at VA
Shown above are the last two cycles of the program or erase command sequence and the last status read cycle
Reset# shown to illustrate tRH measurement references. It cannot occur as shown during a valid command
sequence.
Figure 21. DQ2 vs. DQ6
Enter
Embedded
Erase
Enter Erase
Suspend
Program
Erase
Suspend
Erase
Resume
WE#
Erase
Enter
Suspend
Read
Enter
Suspend
Program
Erase
Suspend
Read
Erase
Complete
Erase
DQ6
DQ2
