Preliminary EN29GL064
AC CHARACTERISTICS
Figure 16. AC Waveforms for Chip/Sector Erase Operations Timings
Erase Command Sequence (last 2 cycles)
Read Status Data (last two cycles)
tAH
tAS
tWC
Addresses
CE#
0x2AA
SA
VA
VA
0x555 for chip
erase
tGHW
OE#
tCH
tWP
WE#
tCS
tWP
tWHWH2 or tWHWH3
Data
0x55
tDS
0x30
Status
DOUT
tBUS
tDH
tRB
RY/BY#
VCC
tVCS
Notes:
1. SA=Sector Address (for sector erase), VA=Valid Address for reading status, Dout=true data at read address.
2. Vcc shown only to illustrate tvcs measurement references. It cannot occur as shown during a valid command
sequence.
