Preliminary EN29GL064
Figure 17. Program Operation Timings
Program Command Sequence (last 2 cycles)
Program Command Sequence (last 2 cycles)
tAS
tAH
tWC
Addresses
CE#
0x555
PA
PA
PA
tGHWL
tCH
OE#
tWP
WE#
tWPH
tWHWH1
tCS
Data
PD
Status
DOUT
OxA0
tDS
tRB
tDH
tBUSY
RY/BY#
tVCS
VCC
Notes:
1. PA=Program Address, PD=Program Data, DOUT is the true data at the program address.
2. VCC shown in order to illustrate tVCS measurement references. It cannot occur as shown during a valid
command sequence.
