Preliminary EN29GL064
AC CHARACTERISTICS
Table 18. Hardware Reset (RESET#)
Speed
-70
10
Parameter
Description
Std
Test
Setup
Unit
RESET# Pulse Width (During Embedded Algorithms)
tRP1
tRP2
tRH
Min
Min
Min
Min
Min
us
ns
ns
ns
ns
RESET# Pulse Width (NOT During Embedded Algorithms)
Reset# High Time Before Read
500
50
RY/BY# Recovery Time ( to CE#, OE# go low)
RY/BY# Recovery Time ( to WE# go low)
Reset# Pin Low (During Embedded Algorithms)
to Read or Write
tRB1
tRB2
tREADY1
0
50
Max
Max
20
us
ns
Reset# Pin Low (NOT During Embedded Algorithms)
to Read or Write
tREADY2
500
Figure 14. AC Waveforms for RESET#
Reset# Timings
