DA14580
FINAL
Bluetooth Low Energy 4.2 SoC
Table 206: P13_MODE_REG (0x5000302C)
Bit
Mode Symbol
R/W PID
Description
Reset
4:0
See P0x_MODE_REG[PID]
0x0
Table 207: P14_MODE_REG (0x5000302E)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:8
-
-
Reserved
R/W
PUPD
00 = Input, no resistors selected
01 = Input, pull-up selected
0x2
10 = Input, Pull-down selected
11 = Output, no resistors selected
In analog mode, these bits are don't care
P14_MODE_REG and P15_MODE_REG reset value is 1
(i.e. pulled up)
7:5
4:0
-
-
Reserved
0x0
0x0
R/W
PID
See P0x_MODE_REG[PID]
Table 208: P15_MODE_REG (0x50003030)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:8
-
-
Reserved
R/W
PUPD
00 = Input, no resistors selected
01 = Input, pull-up selected
0x1
10 = Input, Pull-down selected
11 = Output, no resistors selected
In analog mode, these bits are don't care
P14_MODE_REG and P15_MODE_REG reset value is 1
(i.e. pulled up)
7:5
4:0
-
-
Reserved
0x0
0x0
R/W
PID
See P0x_MODE_REG[PID]
Table 209: P2_DATA_REG (0x50003040)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:0
-
-
Reserved
R/W
P2_DATA
Set P2 output register when written; Returns the value of P2
port when read
0x0
Table 210: P2_SET_DATA_REG (0x50003042)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:0
-
-
Reserved
R/W
P2_SET
Writing a 1 to P2[y] sets P2[y] to 1. Writing 0 is discarded;
Reading returns 0
0x0
Table 211: P2_RESET_DATA_REG (0x50003044)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:0
-
-
Reserved
R/W
P2_RESET
Writing a 1 to P2[y] sets P2[y] to 0. Writing 0 is discarded;
Reading returns 0
0x0
Datasheet
Revision 3.4
09-Nov-2016
CFR0011-120-01
128 of 155
