DA14580
FINAL
Bluetooth Low Energy 4.2 SoC
Table 203: P10_MODE_REG (0x50003026)
Bit
Mode Symbol
Description
Reset
15:10
9:8
-
-
Reserved
0x0
0x2
R/W
PUPD
00 = Input, no resistors selected
01 = Input, pull-up selected
10 = Input, Pull-down selected
11 = Output, no resistors selected
In analog mode, these bits are don't care
P14_MODE_REG and P15_MODE_REG reset value is 1
(i.e. pulled up)
7:5
4:0
-
-
Reserved
0x0
0x0
R/W
PID
See P0x_MODE_REG[PID]
Table 204: P11_MODE_REG (0x50003028)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:8
-
-
Reserved
R/W
PUPD
00 = Input, no resistors selected
01 = Input, pull-up selected
0x2
10 = Input, Pull-down selected
11 = Output, no resistors selected
In analog mode, these bits are don't care
P14_MODE_REG and P15_MODE_REG reset value is 1
(i.e. pulled up)
7:5
4:0
-
-
Reserved
0x0
0x0
R/W
PID
See P0x_MODE_REG[PID]
Table 205: P12_MODE_REG (0x5000302A)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:8
-
-
Reserved
R/W
PUPD
00 = Input, no resistors selected
01 = Input, pull-up selected
0x2
10 = Input, Pull-down selected
11 = Output, no resistors selected
In analog mode, these bits are don't care
P14_MODE_REG and P15_MODE_REG reset value is 1
(i.e. pulled up)
7:5
4:0
-
-
Reserved
0x0
0x0
R/W
PID
See P0x_MODE_REG[PID]
Table 206: P13_MODE_REG (0x5000302C)
Bit
Mode Symbol
Description
Reset
0x0
15:10
9:8
-
-
Reserved
R/W
PUPD
00 = Input, no resistors selected
01 = Input, pull-up selected
0x2
10 = Input, Pull-down selected
11 = Output, no resistors selected
In analog mode, these bits are don't care
P14_MODE_REG and P15_MODE_REG reset value is 1
(i.e. pulled up)
7:5
-
-
Reserved
0x0
Datasheet
Revision 3.4
09-Nov-2016
CFR0011-120-01
127 of 155
