EMI and conducted noise meet EN55022 Class B
Class B test conducted for QBR101S5-12
Class B test conducted for QBR101S12-5
Class B test conducted for QBR101S24-2.5
Class B test conducted for QBR101S48-1.25
Class B test conducted for QBR101S15-4
Class B test conducted for QBR101S28-2.14
(2) EMI Test standard: EN50121-3-2 (EN55011 Class A Conducted & Radiated Emission)
Test Condition: Input Voltage: Nominal, Output Load: Full Load
Model No.
D1
C1
C2
C3
C4
L1
QBR Series
1.5KE180A Littlefuse
220µF/200V YXF 220µF/200V YXF 2200pF
2200pF
1mH
Note: C1, C2 Aluminum Capacitors and C3, C4 Ceramic Capacitors
September 18 2017 B.03
Page 13 of 15
