QUARTER BRICK HEAT SINKS:
0.30
M-C421 (G6620510201)
Transverse Heat Sink
M-C488 (G6620570202)
Longitudinal Heat Sink
All Dimensions in mm
Rca: 4.78°C/W (typ.), At natural convection
2.44°C/W (typ.), At 100LFM
Rca: 5.61°C/W (typ.), At natural convection
4.01°C/W (typ.), At 100LFM
2.06°C/W (typ.), At 200LFM
1.76°C/W (typ.), At 300LFM
3.39°C/W (typ.), At 200LFM
2.86°C/W (typ.), At 300LFM
1.58°C/W (typ.), At 400LFM
2.49°C/W (typ.), At 400LFM
THERMAL PAD: SZ 35.8*56.9*0.25 mm (G6135041041)
SCREW: SMP+SW M3*8L (G75A1300322)
September 18 2017 B.03
Page 7 of 15
