PSoC® 3: CY8C32 Family
Data Sheet
Table 11-25. IDAC DC Specifications (continued)
Parameter
IDD
Description
Conditions
Min
Typ
Max
Units
Operating current, code = 0
Slow mode, source mode, range =
31.875 µA
–
44
100
µA
Slow mode, source mode, range =
255 µA,
–
–
–
–
–
–
–
–
–
–
–
33
33
100
100
100
100
100
500
500
500
500
500
500
µA
µA
µA
µA
µA
µA
µA
µA
µA
µA
µA
Slow mode, source mode, range =
2.04 mA
Slow mode, sink mode, range =
31.875 µA
36
Slow mode, sink mode, range =
255 µA
33
Slow mode, sink mode, range =
2.04 mA
33
Fast mode, source mode, range =
31.875 µA
310
305
305
310
300
300
Fast mode, source mode, range =
255 µA
Fast mode, source mode, range =
2.04 mA
Fast mode, sink mode, range =
31.875 µA
Fast mode, sink mode, range =
255 µA
Fast mode, sink mode, range =
2.04 mA
Figure 11-26. IDAC INL vs Input Code, Range = 255 µA,
Source Mode
Figure 11-27. IDAC INL vs Input Code, Range = 255 µA, Sink
Mode
Document Number: 001-56955 Rev. *J
Page 83 of 119
