Figure 11-58. IMO Frequency Variation vs. Temperature
Figure 11-59. IMO Frequency Variation vs. VCC
11.6.3 Internal Low-Speed Oscillator
Table 11-68. ILO DC Specifications
Parameter
Description
Operating current
Conditions
= 1 kHz
Min
–
Typ
0.3
1.0
1.0
2.0
Max
1.7
2.6
2.6
15
Units
µA
F
F
F
OUT
OUT
OUT
I
= 33 kHz
–
µA
CC
= 100 kHz
–
µA
Leakage current
Power down mode
–
nA
Table 11-69. ILO AC Specifications
Parameter
Description
Startup time, all frequencies
ILO frequencies (trimmed)
100 kHz
Conditions
Turbo mode
Min
Typ
Max
Units
–
–
2
ms
45
100
1
200
2
kHz
kHz
1 kHz
0.5
F
ILO
ILO frequencies (untrimmed)
100 kHz
30
100
1
300
3.5
kHz
kHz
1 kHz
0.3
Figure 11-60. ILO Frequency Variation vs. Temperature
Figure 11-61. ILO Frequency Variation vs. VDD
