CY7C68013A, CY7C68014A
CY7C68015A, CY7C68016A
9.17.3 Sequence Diagram of a Single and Burst Asynchronous Read
Figure 9-21. Slave FIFO Asynchronous Read Sequence and Timing Diagram[20]
t
t
t
t
FAH
SFA
SFA
FAH
FIFOADR
t=0
t
t
t
RDpwh
t
t
t
RDpwl
t
t
T=0
RDpwl
RDpwl
RDpwl
RDpwh
RDpwh
RDpwh
SLRD
SLCS
t=3
t=2
T=2
T=3
T=5
T=4
T=6
t
XFLG
t
XFLG
FLAGS
DATA
SLOE
t
t
XFD
t
XFD
XFD
t
XFD
Data (X)
Driven
N+3
N
N+1
N+2
N
t
t
OEon
t
t
OEoff
OEoff
OEon
t=4
T=1
T=7
t=1
Figure 9-22. Slave FIFO Asynchronous Read Sequence of Events Diagram
SLOE
SLRD
SLRD
SLOE
SLOE
SLRD
N+1
SLRD
N+1
SLRD
N+2
SLRD
N+2
SLOE
FIFO POINTER
N
N
N
N
N+1
N
N+1
N+3
N+2
N+3
FIFO DATA BUS Not Driven
Driven: X
Not Driven
N
N+1
N+1
N+2
Not Driven
Figure 9-21 shows the timing relationship of the SLAVE FIFO
signals during an asynchronous FIFO read. It shows a single
read followed by a burst read.
■ The data that is driven, after asserting SLRD, is the updated
data from the FIFO. This data is valid after a propagation delay
of tXFD from the activating edge of SLRD. In Figure 9-21, data
N is the first valid data read from the FIFO. For data to appear
onthedatabusduringthereadcycle(SLRDisasserted),SLOE
must be in an asserted state. SLRD and SLOE can also be tied
together.
■ At t = 0 the FIFO address is stable and the SLCS signal is
asserted.
■ At t = 1, SLOE is asserted. This results in the data bus being
driven. The data that is driven on to the bus is previous data,
it data that was in the FIFO from a prior read cycle.
The same sequence of events is also shown for a burst read
marked with T = 0 through 5.
■ At t = 2, SLRD is asserted. The SLRD must meet the minimum
active pulse of tRDpwl and minimum de-active pulse width of
Note In burst read mode, during SLOE is assertion, the data bus
is in a driven state and outputs the previous data. After SLRD is
asserted, the data from the FIFO is driven on the data bus (SLOE
must also be asserted) and then the FIFO pointer is
incremented.
t
RDpwh. If SLCS is used then, SLCS must be asserted before
SLRD is asserted (The SLCS and SLRD signals must both be
asserted to start a valid read condition.)
Document #: 38-08032 Rev. *V
Page 53 of 66
