CY7C1361B
CY7C1363B
3.3V TAP AC Test Conditions
2.5V TAP AC Test Conditions
Input pulse levels ........ ........................................VSS to 3.3V
Input rise and fall times...................... ..............................1ns
Input timing reference levels...........................................1.5V
Output reference levels...................................................1.5V
Test load termination supply voltage...............................1.5V
Input pulse levels ......................................... VSS to 2.5V
Input rise and fall time ......................................................1ns
Input timing reference levels................... ......................1.25V
Output reference levels .................. ..............................1.25V
Test load termination supply voltage .................... ........1.25V
3.3V TAP AC Output Load Equivalent
2.5V TAP AC Output Load Equivalent
1.5V
1.25V
50Ω
50Ω
TDO
TDO
ZO= 50Ω
ZO= 50Ω
20pF
20pF
TAP DC Electrical Characteristics And Operating Conditions
(0°C < TA < +70°C; VDD = 3.3V ±0.165V unless otherwise noted)[11]
Parameter
VOH1
Description
Output HIGH Voltage IOH = –4.0 mA
DESCRIPTION
CONDITIONS
VDDQ = 3.3V
MIN
2.4
MAX
UNIT
V
VDDQ = 2.5V
VDDQ = 3.3V
VDDQ = 2.5V
VDDQ = 3.3V
VDDQ = 2.5V
VDDQ = 3.3V
VDDQ = 2.5V
VDDQ = 3.3V
VDDQ = 2.5V
2.0
2.9
2.1
V
V
IOH = –1.0 mA
VOH2
VOL1
VOL2
VIH
Output HIGH Voltage IOH = –100 µA
V
0.4
0.4
V
Output LOW Voltage IOL = 8.0 mA
IOL = 8.0 mA
V
0.2
V
Output LOW Voltage IOL = 100 µA
0.2
V
2.0
1.7
VDD + 0.3
VDD + 0.3
0.7
V
Input HIGH Voltage
Input LOW Voltage
V
VDDQ = 3.3V
–0.5
–0.3
–5
V
VIL
VDDQ = 2.5V
0.7
V
5
µA
IX
Input Load Current
GND < VIN < VDDQ
Note:
11. All voltages referenced to VSS (GND).
