#1
Cut traces on
the score line
on both sides
of the PCB with
knife
#2
Snap apart or
cut with tin
snips
#3
Cut traces on
the score line
on both sides
of the PCB with
knife
#4
Snap apart or
cut with tin
snips
#5
Cut traces on
the score line
on both sides
of the PCB with
knife
#6
Snap apart or
cut with tin
snips
Figure 5: Breaking Out Small Circuit
4.7 TIA / EIA 603
Additional performance measurements are detailed in TIA / EIA - 603 standard. Section 6
outlines Standards for Subaudible Signaling for Land Mobile FM or PM Communications
Equipment.
TIA / EIA standards may be obtained from
(TIA’s address)
(EIA’s address)
Telecommunications Industry Association
2001 Pennsylvania Ave. NW
Suite 800
Electronic Industries Association
1722 Eye Street, NW
Suite 440
Washington, DC 2006
Phone: (202) 457-5430
Fax: (202) 457-4939
Washington, DC 20006
Phone: (202) 457-4936
Fax: (202) 457-4966
An alternative source is Global Engineering Documents, 15 Inverness Way East, Englewood, CO
80112 Phone: (800) 854-7179 (They accept Credit card orders) Global is a company that
specializes in reprinting standards and is a good source to quickly get many types of standards.
Page 13
20480150.001 MX-COM ꢀ 1996
