INSTRUCTION FORMAT (continued)
Global Transfer Data Register (DR) to Wiper Control Register (WCR)
S
T
O
P
S
T
A
R
T
A
C
K
A
C
K
DEVICE ADDRESS
INSTRUCTION
0 1 0 1 A3 A2 A1 A0
0 0 0 1 R1 R0 0 0
Global Transfer Wiper Control Register (WCR) to Data Register (DR)
S
T
O
P
S
T
A
R
T
A
C
K
A
C
K
DEVICE ADDRESS
INSTRUCTION
0 1 0 1 A3 A2 A1 A0
1 0 0 0 R1 R0 0 0
Transfer Wiper Control Register (WCR) to Data Register (DR)
S
T
O
P
S
T
A
R
T
A
C
K
A
C
K
DEVICE ADDRESS
INSTRUCTION
0 1 0 1 A3 A2 A1 A0
1 1 1 0 R1 R0 0 P0
Transfer Data Register (DR) to Wiper Control Register (WCR)
S
T
O
P
S
T
A
R
T
A
C
K
A
C
K
DEVICE ADDRESS
INSTRUCTION
0 1 0 1 A3 A2 A1 A0
1 1 0 1 R1 R0 0 P0
Increment (I)/Decrement (D) Wiper Control Register (WCR)
S
T
A
R
T
A
C
K
S
T
O
P
A
C
K
A
C
K
DEVICE ADDRESS
INSTRUCTION
DATA
0 1 0 1 A3 A2 A1 A0
0 0 1 0 0 0 0 P0
I/D I/D
I/D I/D
• • •
Notes:
(1) Any write or transfer to the Non-volatile Data Registers is followed by a high voltage cycle after a STOP has been issued.
