C-Series Circuit Breaker – General Specifications
Electrical Tables
Table E: Lists UL Recognized, CSA Accepted configurations and performance capabilities as Protectors, Supplementary for
Marine Electrical and Fuel Systems (Guide PEQZ2, File E75596). Ignition Protected per UL 1500. UL Classified Small Craft
Electrical Devices, Marine in accordance with ISO 8846 (Guide UZMK, File MQ1515) as Marine Supplementary Protectors.
C-SERIES TABLE E: UL1500 (Marine Ignition Protection)
Interrupting
Capacity (Amps)
Voltage
Current Rating
Application Codes
Circuit
Configuration
Construction
Notes
Max.
Rating
Full Load
Amps
Without
Backup Fuse
Frequency
Phase
---
UL
CSA
0.02 - 100
101 - 150
0.02 - 100
0.02 - 70
0.02 - 70
71 - 100
48
DC
5,000
TC1, 2, OL1, U1
TC1, 2, OL1, U1
---
65
80
DC
DC
---
---
1,500
1,500
5,000
1,500
TC1, 2, OL0, U1
TC1, 2, OL1, U1
TC1, 2, OL0, U1
TC1, 2, OL1, U1
---
---
Series
125
50 / 60
1
TC1, 2, OL1, U1
TC1, 2, OL1, U1
---
---
0.02 - 70
50 / 60
1
250
1,500
TC1, 2, OL1, U1
TC1, 2, OL1, U1
2 Poles Breaking
Single Phase
71 - 100
Table F: Lists UL Listed configurations and performance capabilities as Circuit Breakers for use in Communications Equipment
(Guide DITT, File E189195), under UL489A.
C-SERIES TABLE F: PARALLEL POLE CONSTRUCTION
UL489A Listed for Communications Equipment
Voltage
Max. Rating
80
Current Rating
Interrupting Capacity (Amps)
Without Backup Fuse
Circuit
Configuration
Frequency
DC
General Purpose Amps
Series
100 - 250
10,000
Agency Certifications
Component Supplementary
Protector under Class 3215 30,
FIle 047848 0 000 CSA
UL Recognized
UL Standard 1077
CSA Accepted
Component Recognition Program
as Protectors Supplementary
(Guide CCN/QVNU2, File E75596)
Standard C22.2 No. 235
Switches, Industrial Control
(Guide CCN/NRNT2, File E148683)
Circuit Breaker Model Case
(Class 1432 01, File 093910),
CSA Standard C22.2 No. 5.1 - M
UL Standard 508
UL Standard 1500
CSA Certified
TUV Certified
VDE Certified
Protectors, Supplementary for
Marine Electrical & Fuel Systems
(Guide PEQZ2, File E75596)
Ignition Protection
EN60934, under License No.
R72040875
UL Listed
UL Standard 489
Circuit Breakers, Molded Case,
(Guide DIVQ, File E129899)
EN60934, VDE 0642 under File
No. 10537
Communications Equipment
UL Standard 489A
(Guide CCN/DITT, File E189195)
