PIN CONFIGURATION
ELECTROSTATIC
DISCHARGE SENSITIVITY
TOP VIEW
SO-8
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
Ref
–In
+In
V–
1
2
3
4
8
7
6
5
NC
V+
Out
NC
ESD damage can range from subtle performance degradation
to complete device failure. Precision integrated circuits may
be more susceptible to damage because very small parametric
changes could cause the device not to meet its published
specifications.
ABSOLUTE MAXIMUM RATINGS(1)
Supply Voltage, V+ to V– .................................................................... 36V
Signal Input Terminals, Continuous ................................................ ±200V
Peak (0.1s) ............................................... ±500V
Output Short Circuit to GND Duration .................................... Continuous
Operating Temperature ..................................................–55°C to +125°C
Storage Temperature .....................................................–55°C to +125°C
Junction Temperature .................................................................... +150°C
Lead Temperature (soldering, 10s) ............................................... +300°C
NOTE: (1) Stresses above these ratings may cause permanent damage.
Exposure to absolute maximum conditions for extended periods may degrade
device reliability. These are stress ratings only, and functional operation of the
device at these or any other conditions beyond those specified is not implied.
PACKAGE/ORDERING INFORMATION
PACKAGE
SPECIFIED
DRAWING
NUMBER
TEMPERATURE
RANGE
PACKAGE
MARKING
ORDERING
NUMBER(1)
TRANSPORT
MEDIA
PRODUCT
PACKAGE
INA148UA
SO-8
182
–40°C to +85°C
INA148UA
INA148UA
Rails
"
"
"
"
"
INA148UA/2K5
Tape and Reel
NOTE: (1) Models with a slash (/) are available only in Tape and Reel in the quantities indicated (e.g., /2K5 indicates 2500 devices per reel). Ordering 2500 pieces
of “INA148UA/2K5” will get a single 2500-piece Tape and Reel.
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change
without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not authorize or warrant
any BURR-BROWN product for use in life support devices and/or systems.
®
