SMPS Capacitors (SE Style)
Extended Commercial Radial Range
PRODUCT OFFERING – X7R
AVX SE styles offer capacitance extension to popular SK ranges. The CV
product for SE-series, X7R capacitors (TCC: 15ꢀ over -55 to +125°C)
compares favorably to high CV ranges offered by other suppliers in much
less stable Y5U dielectric (TCC: +22/-56ꢀ over -30 to +85°C). SE style
capacitors are conformally coated and are designed for input and output
filtering applications in switch mode power supplies.
ELECTRICAL SPECIFICATIONS
Temperature Coefficient
Dielectric Withstanding Voltage 25°C (Flash Test)
X7R: Temperature Coefficient 15ꢀ, -55° to +125°C
Capacitance Test (MIL-STD-202 Method 305)
X7R: 25°C, 1.0 0.2 Vrms (open circuit voltage) at 1KHz
Dissipation Factor 25°C
X7R: 250ꢀ rated voltage for 5 seconds with 50 mA max
charging current.
Life Test (1000 hrs)
X7R: 200ꢀ rated voltage at +125°C
X7R: 2.5ꢀ Max @ 25°C, 1.0 0.2 Vrms (open circuit voltage) at 1KHz
Insulation Resistance 25°C (MIL-STD-202 Method 302)
X7R: 100K MΩ or 1000 MΩ-μF, whichever is less.
Insulation Resistance 125°C (MIL-STD-202 Method 302)
X7R: 10K MΩ or 100 MΩ-μF, whichever is less.
Moisture Resistance (MIL-STD-202 Method 106)
X7R: Ten cycles with no voltage applied.
Thermal Shock (MIL-STD-202 Method 107, Condition A)
Immersion Cycling (MIL-STD-202 Method 104, Condition B)
Resistance To Solder Heat (MIL-STD-202, Method 210,
Condition B, for 20 seconds)
HOW TO ORDER
SE
01
3
C
125
M
A
A
*
Style
Size
See chart
below
Voltage
25V = 3
50V = 5
Temperature
Coefficient
X7R = C
Capacitance
Code
(2 significant
digits + no.
of zeros)
Capacitance
Tolerance
X7R: K = 10ꢀ
M = 20ꢀ
Test
Leads
Packaging
Level
A = Tin/Lead (See Note 1)
A = Standard R = RoHS
B = Hi-Rel
100V = 1
Compliant
*
Z = +80, -20ꢀ
22 nF = 223
220 nF = 224
1 μF = 105
100 μF = 107
Note 1: No suffix signifies bulk packaging,
which is AVX standard packaging.
Parts available tape and reel per EIA-
468. Use suffix “TR1” if tape & reel is
required.
Note: Capacitors with X7R dielectrics are not intended for applications across
AC supply mains or AC line filtering with polarity reversal. Contact plant for
recommendations.
Hi-Rel screening consists of 100ꢀ Group A, Subgroup 1 per MIL-PRF-39014.
*
TAPE & REEL QUANTITY
RoHS
Part
Pieces
2000
1000
1000
500
Part
Available
Yes
SE01
SE01
SE03/SE53
SE04/SE54
SE05/SE55
SE06/SE56
SE03/SE53
SE04/SE54
SE05/SE55
SE06/SE56
Yes
Yes
Yes
500
Yes
50
