ESCC Qualified SMPS Capacitors
High Voltage Chip/Leaded Capacitors
HIGH VOLTAGE CHIP CAPACITORS
Capacitors, Fixed, Chip, Ceramic Dielectric, Type II, High
Voltage, Based on Styles 1812 and 1825 for use in ESCC
space programs, according to ESCC Generic Specification
3009 and associated Detail Specification 3009/034 as
recommended by the Space Components Coordination
Group. (ranges in table below)
Note: Variants 01 to 12: metallized pads
Rated
Size
Variant
Voltage Tolerance Capacitance
(kV)
(%)
Code (E12)
1812
01
02
03
04
05
06
07
08
09
10
11
12
10
20
10
20
10
20
10
20
10
20
10
20
HOW TO ORDER
1.0
392 - 223
Parts should be ordered using the ESCC variant number as follows:
2.0
3.0
1.0
2.0
3.0
152 - 182
821 - 102
273 - 563
222 - 682
821 - 392
3009034 XX
B
XXX
Type
Variant
(per table)
Test Level
C = Standard test level
B = Level C plus serialized
and capacitance
Capacitance
Code
Detail Spec
Number
1825
The first two digits represent
significant figures and the third
digit specifies the number of
zeros to follow; i.e.
102 = 1000pF
recorded before and
after 100ꢀ burn-in.
103 = 10000pF
Eg 300903401C223
HIGH VOLTAGE LEADED CAPACITORS
Capacitors, Fixed, Ceramic Dielectric, Type II, High Voltage,
1.0 to 5.0 kV, Based on Case Styles VR, CV and CH for use
in ESCC space programs, according to ESCC Generic
Specification 3001 and associated Detail Specification
3001/034 as recommended by the Space Components
Coordination Group. (ranges in table)
Capacitance Code (E12)
2.0kV 3.0kV 4.0kV
392 - 203 152 - 182 821 - 102
273 - 563 222 - 682 821 - 392
Case
Size
Lead
Type
Variant
1.0kV
5.0kV
VR30S
VR30
VR40
VR50
VR66
VR84
VR90
CV41
CH41
CH41
CV51
CH51
CH51
CV61
CH61
CH61
CV76
CH76
CH76
CV91
CH91
CH91
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
a
a
a
a
a
a
a
b
c
d
b
c
d
b
c
d
b
c
d
b
c
d
473 - 124 822 - 153 472 - 103 182 - 222
154 - 274 183 - 333 123 - 183 562 - 822 332 - 392
224 - 564 393 - 823 223 - 393 103 - 153 682 - 103
684 - 105 473 - 154 473 - 683 183 - 393 123 - 183
125 - 275 184 - 334 823 - 184 473 - 124 223 - 563
473 - 124 822 - 153 472 - 103 182 - 222
Note 1: Lead Types
a - Leaded Radial (epoxy coated)
b - Leaded Radial (Polyurethane Varnish)
c - Straight Dual in Line
473 - 124 822 - 153 472 - 103 182 - 222
473 - 124 822 - 153 472 - 103 182 - 222
d - L Dual in Line
154 - 274 183 - 333 123 - 183 562 - 822 332 - 392
154 - 274 183 - 333 123 - 183 562 - 822 332 - 392
154 - 274 183 - 333 123 - 183 562 - 822 332 - 392
224 - 564 393 - 823 223 - 393 103 - 153 682 - 103
224 - 564 393 - 823 223 - 393 103 - 153 682 - 103
224 - 564 393 - 823 223 - 393 103 - 153 682 - 103
684 - 105 473 - 154 473 - 683 183 - 393 123 - 183
684 - 105 473 - 154 473 - 683 183 - 393 123 - 183
684 - 105 473 - 154 473 - 683 183 - 393 123 - 183
125 - 275 184 - 334 823 - 184 473 - 124 223 - 563
125 - 275 184 - 334 823 - 184 473 - 124 223 - 563
125 - 275 184 - 334 823 - 184 473 - 124 223 - 563
Note 2: Tolerances of 10ꢀ and 20ꢀ are available
HOW TO ORDER
Parts should be ordered using the ESCC variant
number as follows:
3001034
XX
B
XXX
K
X
Type Variant
Test Level
C = Standard test level
B = Level C plus serialized
and capacitance recorded
before and after 100ꢀ
burn-in.
Capacitance
Code
The first two digits represent
significant figures and the third
digit specifies the number of
zeros to follow; i.e.
Capacitance
Tolerance
K = 10ꢀ
Voltage
M = 1kV
P = 2kV
R = 3kV
S = 4kV
Z = 5kV
Detail Spec
Number
(per table above)
M = 20ꢀ
102 = 1000pF
103 = 10000pF
Eg 300103412C274KM
