Compare Match Output
Unit
The Compare Output mode (COM0A1:0) bits have two functions. The Waveform Gener-
ator uses the COM0A1:0 bits for defining the Output Compare (OC0A) state at the next
compare match. Also, the COM0A1:0 bits control the OC0A pin output source. Figure 40
shows a simplified schematic of the logic affected by the COM0A1:0 bit setting. The I/O
Registers, I/O bits, and I/O pins in the figure are shown in bold. Only the parts of the
general I/O port control registers (DDR and PORT) that are affected by the COM0A1:0
bits are shown. When referring to the OC0A state, the reference is for the internal OC0A
Register, not the OC0A pin. If a system reset occur, the OC0A Register is reset to “0”.
Figure 40. Compare Match Output Unit, Schematic
COMnx1
Waveform
Generator
COMnx0
FOCnx
D
Q
1
0
OCnx
Pin
OCnx
D
Q
PORT
D
Q
DDR
clkI/O
Compare Output Function
The general I/O port function is overridden by the Output Compare (OC0A) from the
Waveform Generator if either of the COM0A1:0 bits are set. However, the OC0A pin
direction (input or output) is still controlled by the Data Direction Register (DDR) for the
port pin. The Data Direction Register bit for the OC0A pin (DDR_OC0A) must be set as
output before the OC0A value is visible on the pin. The port override function is indepen-
dent of the Waveform Generation mode.
The design of the Output Compare pin logic allows initialization of the OC0A state
before the output is enabled. Note that some COM0A1:0 bit settings are reserved for
certain modes of operation. See “8-bit Timer/Counter Register Description” on page 104
Compare Output Mode and
Waveform Generation
The Waveform Generator uses the COM0A1:0 bits differently in Normal, CTC, and
PWM modes. For all modes, setting the COM0A1:0 = 0 tells the Waveform Generator
that no action on the OC0A Register is to be performed on the next compare match. For
compare output actions in the non-PWM modes refer to Table 55 on page 105. For fast
PWM mode, refer to Table 56 on page 105, and for phase correct PWM refer to Table
57 on page 106.
A change of the COM0A1:0 bits state will have effect at the first compare match after the
bits are written. For non-PWM modes, the action can be forced to have immediate effect
by using the FOC0A strobe bits.
98
AT90CAN128
4250E–CAN–12/04
