ATmega64A
Table 27-16. JTAG Programming Instruction Set (Continued)
a = address high bits, b = address low bits, H = 0 - Low byte, 1 - High Byte, o = data out, i = data in, x = don’t care
Instruction
TDI sequence
TDO sequence
Notes
8f. Read Fuses and Lock Bits
0111010_00000000
0111110_00000000
0110010_00000000
0110110_00000000
0110111_00000000
xxxxxxx_xxxxxxxx
xxxxxxx_oooooooo
xxxxxxx_oooooooo
xxxxxxx_oooooooo
xxxxxxx_oooooooo
(5)
Fuse Ext. byte
Fuse High byte
Fuse Low byte
Lock bits
9a. Enter Signature Byte Read
9b. Load Address Byte
0100011_00001000
xxxxxxx_xxxxxxxx
xxxxxxx_xxxxxxxx
0000011_bbbbbbbb
9c. Read Signature Byte
0110010_00000000
0110011_00000000
xxxxxxx_xxxxxxxx
xxxxxxx_oooooooo
10a. Enter Calibration Byte Read
10b. Load Address Byte
0100011_00001000
xxxxxxx_xxxxxxxx
xxxxxxx_xxxxxxxx
0000011_bbbbbbbb
10c. Read Calibration Byte
0110110_00000000
0110111_00000000
xxxxxxx_xxxxxxxx
xxxxxxx_oooooooo
Note:
1. This command sequence is not required if the seven MSB are correctly set by the previous command sequence (which is
normally the case).
2. Repeat until o = “1”.
3. Set bits to “0” to program the corresponding fuse, “1” to unprogram the fuse.
4. Set bits to “0” to program the corresponding Lock bit, “1” to leave the Lock bit unchanged.
5. “0” = programmed, “1” = unprogrammed.
6. The bit mapping for Fuses Extended byte is listed in Table 27-3 on page 296.
7. The bit mapping for Fuses High byte is listed in Table 27-4 on page 297.
8. The bit mapping for Fuses Low byte is listed in Table 27-5 on page 297.
9. The bit mapping for Lock bits byte is listed in Table 27-1 on page 295.
10. Address bits exceeding PCMSB and EEAMSB (Table 27-9 and Table 27-10) are don’t care.
321
8160C–AVR–07/09
