ATmega48PA/88PA/168PA/328P
Table 17-9. Clock Select Bit Description
CS22
CS21
CS20
Description
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
No clock source (Timer/Counter stopped).
clkT2S/(No prescaling)
clkT2S/8 (From prescaler)
clkT2S/32 (From prescaler)
clkT2S/64 (From prescaler)
clkT2S/128 (From prescaler)
clkT S/256 (From prescaler)
2
clkT S/1024 (From prescaler)
2
If external pin modes are used for the Timer/Counter0, transitions on the T0 pin will clock the
counter even if the pin is configured as an output. This feature allows software control of the
counting.
17.11.3 TCNT2 – Timer/Counter Register
Bit
7
6
5
4
3
2
1
0
(0xB2)
TCNT2[7:0]
TCNT2
Read/Write
Initial Value
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
The Timer/Counter Register gives direct access, both for read and write operations, to the
Timer/Counter unit 8-bit counter. Writing to the TCNT2 Register blocks (removes) the Compare
Match on the following timer clock. Modifying the counter (TCNT2) while the counter is running,
introduces a risk of missing a Compare Match between TCNT2 and the OCR2x Registers.
17.11.4 OCR2A – Output Compare Register A
Bit
7
6
5
4
3
2
1
0
(0xB3)
OCR2A[7:0]
OCR2A
Read/Write
Initial Value
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
The Output Compare Register A contains an 8-bit value that is continuously compared with the
counter value (TCNT2). A match can be used to generate an Output Compare interrupt, or to
generate a waveform output on the OC2A pin.
17.11.5 OCR2B – Output Compare Register B
Bit
7
6
5
4
3
2
1
0
(0xB4)
OCR2B[7:0]
OCR2B
Read/Write
Initial Value
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
The Output Compare Register B contains an 8-bit value that is continuously compared with the
counter value (TCNT2). A match can be used to generate an Output Compare interrupt, or to
generate a waveform output on the OC2B pin.
162
8161D–AVR–10/09
