ATmega8(L)
Figure 107. Programming the EEPROM Waveforms
K
A
G
B
C
E
B
C
E
L
0x11
ADDR. HIGH ADDR. LOW
DATA
ADDR. LOW
DATA
XX
XX
DATA
XA1
XA0
BS1
XTAL1
WR
RDY/BSY
RESET +12V
OE
PAGEL
BS2
Reading the Flash
The algorithm for reading the Flash memory is as follows (refer to “Programming the Flash” on
page 222 for details on Command and Address loading):
1. A: Load Command “0000 0010”
2. G: Load Address High byte (0x00 - 0xFF)
3. B: Load Address Low byte (0x00 - 0xFF)
4. Set OE to “0”, and BS1 to “0”. The Flash word Low byte can now be read at DATA
5. Set BS1 to “1”. The Flash word High byte can now be read at DATA
6. Set OE to “1”
Reading the EEPROM The algorithm for reading the EEPROM memory is as follows (refer to “Programming the Flash”
on page 222 for details on Command and Address loading):
1. A: Load Command “0000 0011”
2. G: Load Address High byte (0x00 - 0xFF)
3. B: Load Address Low byte (0x00 - 0xFF)
4. Set OE to “0”, and BS1 to “0”. The EEPROM Data byte can now be read at DATA
5. Set OE to “1”
Programming the
Fuse Low Bits
The algorithm for programming the Fuse Low bits is as follows (refer to “Programming the Flash”
on page 222 for details on Command and Data loading):
1. A: Load Command “0100 0000”
2. C: Load Data Low byte. Bit n = “0” programs and bit n = “1” erases the Fuse bit
3. Set BS1 and BS2 to “0”
4. Give WR a negative pulse and wait for RDY/BSY to go high
225
2486AA–AVR–02/2013
