Figure 9-2. MCU Start-up, RESET Tied to VCC
VPOT
VCC
VRST
RESET
tTOUT
TIME-OUT
INTERNAL
RESET
Figure 9-3. MCU Start-up, RESET Extended Externally
VPOT
VCC
VRST
RESET
tTOUT
TIME-OUT
INTERNAL
RESET
9.2.2
External Reset
An External Reset is generated by a low level on the RESET pin. Reset pulses longer than the
minimum pulse width (see Table 9-1 on page 47) will generate a reset, even if the clock is not
running. Shorter pulses are not guaranteed to generate a reset. When the applied signal
reaches the Reset Threshold Voltage – VRST – on its positive edge, the delay counter starts the
MCU after the Time-out period – tTOUT – has expired.
Figure 9-4. External Reset During Operation
CC
