 浏览型号ATMEGA128L-8AL的Datasheet PDF文件第135页浏览型号ATMEGA128L-8AL的Datasheet PDF文件第136页浏览型号ATMEGA128L-8AL的Datasheet PDF文件第137页浏览型号ATMEGA128L-8AL的Datasheet PDF文件第138页浏览型号ATMEGA128L-8AL的Datasheet PDF文件第140页浏览型号ATMEGA128L-8AL的Datasheet PDF文件第141页浏览型号ATMEGA128L-8AL的Datasheet PDF文件第142页浏览型号ATMEGA128L-8AL的Datasheet PDF文件第143页
ATmega128(L)
Output Compare
Register 3 B –
Bit
7
6
5
4
3
2
1
0
OCR3BH and OCR3BL
OCR3B[15:8]
OCR3B[7:0]
OCR3BH
OCR3BL
R/W
Read/Write
Initial Value
R/W
0
R/W
0
R/W
0
R/W
R/W
0
R/W
0
R/W
0
0
0
Output Compare
Register 3 C –
Bit
7
6
5
4
3
2
1
0
OCR3CH and OCR3CL
OCR3C[15:8]
OCR3C[7:0]
OCR3CH
OCR3CL
R/W
Read/Write
Initial Value
R/W
0
R/W
0
R/W
0
R/W
R/W
0
R/W
0
R/W
0
0
0
The Output Compare Registers contain a 16-bit value that is continuously compared with the
counter value (TCNTn). A match can be used to generate an output compare interrupt, or to
generate a waveform output on the OCnx pin.
The Output Compare Registers are 16-bit in size. To ensure that both the high and low bytes are
written simultaneously when the CPU writes to these registers, the access is performed using an
8-bit temporary High Byte Register (TEMP). This Temporary Register is shared by all the other
16-bit registers. See “Accessing 16-bit Registers” on page 115.
Input Capture Register
1 – ICR1H and ICR1L
Bit
7
6
5
4
3
2
1
0
ICR1[15:8]
ICR1[7:0]
ICR1H
ICR1L
Read/Write
Initial Value
R/W
0
R/W
0
R/W
0
R/W
R/W
0
R/W
0
R/W
0
R/W
0
0
Input Capture Register
3 – ICR3H and ICR3L
Bit
7
6
5
4
3
2
1
0
ICR3[15:8]
ICR3[7:0]
ICR3H
ICR3L
Read/Write
Initial Value
R/W
0
R/W
0
R/W
0
R/W
R/W
0
R/W
0
R/W
0
R/W
0
0
The Input Capture is updated with the counter (TCNTn) value each time an event occurs on the
ICPn pin (or optionally on the Analog Comparator Output for Timer/Counter1). The Input Cap-
ture can be used for defining the counter TOP value.
The Input Capture Register is 16-bit in size. To ensure that both the high and low bytes are read
simultaneously when the CPU accesses these registers, the access is performed using an 8-bit
temporary High Byte Register (TEMP). This Temporary Register is shared by all the other 16-bit
registers. See “Accessing 16-bit Registers” on page 115.
Timer/Counter
Interrupt Mask
Register – TIMSK
Bit
7
OCIE2
R/W
0
6
TOIE2
R/W
0
5
TICIE1
R/W
0
4
OCIE1A
R/W
0
3
OCIE1B
R/W
0
2
TOIE1
R/W
0
1
OCIE0
R/W
0
0
TOIE0
R/W
0
TIMSK
Read/Write
Initial Value
Note:
This register contains interrupt control bits for several Timer/Counters, but only Timer1 bits are
described in this section. The remaining bits are described in their respective timer sections.
• Bit 5 – TICIE1: Timer/Counter1, Input Capture Interrupt Enable
139
2467P–AVR–08/07
