26. ADC – Analog to Digital Converter
26.1 Features
• 10-bit Resolution
• 1 LSB Integral Non-linearity
•
2 LSB Absolute Accuracy
• 13 - 260 µs Conversion Time
• Up to 76.9 kSPS (Up to 15 kSPS at Maximum Resolution)
• 16 Multiplexed Single Ended Input Channels
• 14 Differential input channels
• 4 Differential Input Channels with Optional Gain of 10x and 200x
• Optional Left Adjustment for ADC Result Readout
• 0 - VCC ADC Input Voltage Range
• 2.7 - VCC Differential ADC Voltage Range
• Selectable 2.56V or 1.1V ADC Reference Voltage
• Free Running or Single Conversion Mode
• Interrupt on ADC Conversion Complete
• Sleep Mode Noise Canceler
The ATmega640/1280/1281/2560/2561 features a 10-bit successive approximation ADC. The
ADC is connected to an 8/16-channel Analog Multiplexer which allows eight/sixteen single-
ended voltage inputs constructed from the pins of Port A and Port F. The single-ended voltage
inputs refer to 0V (GND).
The device also supports 16/32 differential voltage input combinations. Four of the differential
inputs (ADC1 & ADC0, ADC3 & ADC2, ADC9 & ADC8 and ADC11 & ADC10) are equipped with
a programmable gain stage, providing amplification steps of 0 dB (1x), 20 dB (10x) or 46 dB
(200x) on the differential input voltage before the ADC conversion. The 16 channels are split in
two sections of 8 channels where in each section seven differential analog input channels share
a common negative terminal (ADC1/ADC9), while any other ADC input in that section can be
selected as the positive input terminal. If 1x or 10x gain is used, 8 bit resolution can be expected.
If 200x gain is used, 7 bit resolution can be expected.
The ADC contains a Sample and Hold circuit which ensures that the input voltage to the ADC is
held at a constant level during conversion. A block diagram of the ADC is shown in Figure 26-1.
The ADC has a separate analog supply voltage pin, AVCC. AVCC must not differ more than
0.3V from VCC. See the paragraph “ADC Noise Canceler” on page 283 on how to connect this
pin.
Internal reference voltages of nominally 1.1V, 2.56V or AVCC are provided On-chip. The volt-
age reference may be externally decoupled at the AREF pin by a capacitor for better noise
performance.
The Power Reduction ADC bit, PRADC, in “PRR0 – Power Reduction Register 0” on page 56
must be disabled by writing a logical zero to enable the ADC.
