ATmega640/1280/1281/2560/2561
Enabling and disabling of the clock input must be done when Tn has been stable for at least one
system clock cycle, otherwise it is a risk that a false Timer/Counter clock pulse is generated.
Each half period of the external clock applied must be longer than one system clock cycle to
ensure correct sampling. The external clock must be guaranteed to have less than half the sys-
tem clock frequency (fExtClk < fclk_I/O/2) given a 50/50% duty cycle. Since the edge detector uses
sampling, the maximum frequency of an external clock it can detect is half the sampling fre-
quency (Nyquist sampling theorem). However, due to variation of the system clock frequency
and duty cycle caused by Oscillator source (crystal, resonator, and capacitors) tolerances, it is
recommended that maximum frequency of an external clock source is less than fclk_I/O/2.5.
An external clock source can not be prescaled.
Figure 18-2. Prescaler for synchronous Timer/Counters
clkI/O
Clear
PSR10
Tn
Synchronization
Tn
Synchronization
CSn0
CSn1
CSn2
CSn0
CSn1
CSn2
TIMER/COUNTERn CLOCK SOURCE
clkTn
TIMER/COUNTERn CLOCK SOURCE
clkTn
18.4 Register Description
18.4.1
GTCCR – General Timer/Counter Control Register
Bit
7
6
5
4
3
2
1
0
0x23 (0x43)
Read/Write
Initial Value
TSM
R/W
0
PSRASY PSRSYNC
GTCCR
R
0
R
0
R
0
R
0
R
0
R/W
R/W
0
0
• Bit 7 – TSM: Timer/Counter Synchronization Mode
Writing the TSM bit to one activates the Timer/Counter Synchronization mode. In this mode, the
value that is written to the PSRASY and PSRSYNC bits is kept, hence keeping the correspond-
ing prescaler reset signals asserted. This ensures that the corresponding Timer/Counters are
halted and can be configured to the same value without the risk of one of them advancing during
configuration. When the TSM bit is written to zero, the PSRASY and PSRSYNC bits are cleared
by hardware, and the Timer/Counters start counting simultaneously.
• Bit 0 – PSRSYNC: Prescaler Reset for Synchronous Timer/Counters
When this bit is one, Timer/Counter0, Timer/Counter1, Timer/Counter3, Timer/Counter4 and
Timer/Counter5 prescaler will be Reset. This bit is normally cleared immediately by hardware,
171
2549L–AVR–08/07
