AT90USB64/128
caler bits to zero when checking the Status bits. This makes status checking independent of
prescaler setting. This approach is used in this datasheet, unless otherwise noted.
• Bit 2 – Res: Reserved Bit
This bit is reserved and will always read as zero.
• Bits 1..0 – TWPS: TWI Prescaler Bits
These bits can be read and written, and control the bit rate prescaler.
Table 20-2. TWI Bit Rate Prescaler
TWPS1
TWPS0
Prescaler Value
0
0
1
1
0
1
0
1
1
4
16
64
To calculate bit rates, see “Bit Rate Generator Unit” on page 223. The value of TWPS1..0 is
used in the equation.
20.6.4
TWI Data Register – TWDR
Bit
7
TWD7
R/W
1
6
TWD6
R/W
1
5
TWD5
R/W
1
4
TWD4
R/W
1
3
TWD3
R/W
1
2
TWD2
R/W
1
1
TWD1
R/W
1
0
TWD0
R/W
1
TWDR
Read/Write
Initial Value
In Transmit mode, TWDR contains the next byte to be transmitted. In Receive mode, the TWDR
contains the last byte received. It is writable while the TWI is not in the process of shifting a byte.
This occurs when the TWI Interrupt Flag (TWINT) is set by hardware. Note that the Data Regis-
ter cannot be initialized by the user before the first interrupt occurs. The data in TWDR remains
stable as long as TWINT is set. While data is shifted out, data on the bus is simultaneously
shifted in. TWDR always contains the last byte present on the bus, except after a wake up from
a sleep mode by the TWI interrupt. In this case, the contents of TWDR is undefined. In the case
of a lost bus arbitration, no data is lost in the transition from Master to Slave. Handling of the
ACK bit is controlled automatically by the TWI logic, the CPU cannot access the ACK bit directly.
• Bits 7..0 – TWD: TWI Data Register
These eight bits constitute the next data byte to be transmitted, or the latest data byte received
on the 2-wire Serial Bus.
20.6.5
TWI (Slave) Address Register – TWAR
Bit
7
6
5
TWA4
R/W
1
4
TWA3
R/W
1
3
TWA2
R/W
1
2
TWA1
R/W
1
1
TWA0
R/W
1
0
TWGCE
R/W
0
TWA6
R/W
1
TWA5
R/W
1
TWAR
Read/Write
Initial Value
The TWAR should be loaded with the 7-bit Slave address (in the seven most significant bits of
TWAR) to which the TWI will respond when programmed as a Slave Transmitter or Receiver,
and not needed in the Master modes. In multimaster systems, TWAR must be set in masters
which can be addressed as Slaves by other Masters.
227
7593A–AVR–02/06
