AT85C51SND3Bx
Table 128. UEDATX Register
UEDATX (1.D3h) – USB Endpoint Data Register
7
6
5
4
3
2
1
0
DAT7
DAT6
DAT5
DAT4
DAT3
DAT2
DAT1
DAT0
Bit
Bit
Number
Mnemonic Description
Data Bits
7-0
DAT7:0
Set by the software to read/write a byte from/to the endpoint FIFO selected by
EPNUM.
Reset Value = 0000 0000b
Table 129. UEBCHX Register
UEBCHX (1.D4h) – USB Endpoint Byte Counter High Register
7
6
5
4
3
2
1
0
-
-
-
-
-
BYCT10
BYCT9
BYCT8
Bit
Bit
Number
Mnemonic Description
Reserved
7-3
2-0
-
The value read from these bits is always 0. Do not set these bits.
Byte count (high) Bits
BYCT10:8
Set by hardware. This field is the MSB of the byte count of the FIFO endpoint.
The LSB part is provided by the UEBCLX register.
Reset Value = 0000 0000b
Table 130. UEBCLX Register
UEBCLX (1.D5h) – USB Endpoint Byte Counter Low Register
7
6
5
4
3
2
1
0
BYCT7
BYCT6
BYCT5
BYCT4
BYCT3
BYCT2
BYCT1
BYCT0
Bit
Bit
Number
Mnemonic Description
Byte Count (low) Bits
Set by the hardware. BYCT10:0 is:
(for IN endpoint) increased after each writing into the endpoint and
-
7-0
BYCT7:0
decremented after each byte sent,
- (for OUT endpoint) increased after each byte sent by the host, and
decremented after each byte read by the software.
Reset Value = 0000 0000b
125
7632A–MP3–03/06
