AT8xC51SND2C
Interrupt
The Serial I/O Port handles 2 interrupt sources that are the “end of reception” (RI in
SCON) and “end of transmission” (TI in SCON) flags. As shown in Figure 129 these
flags are combined together to appear as a single interrupt source for the C51 core.
Flags must be cleared by software when executing the serial interrupt service routine.
The serial interrupt is enabled by setting ES bit in IEN0 register. This assumes interrupts
are globally enabled by setting EA bit in IEN0 register.
Depending on the selected mode and weather the framing error detection is enabled or
disabled, RI flag is set during the stop bit or during the ninth bit as detailed in Figure 130.
Figure 129. Serial I/O Interrupt System
SCON.0
RI
Serial I/O
Interrupt Request
TI
ES
IEN0.4
SCON.1
Figure 130. Interrupt Waveforms
a. Mode 1
RXD
D0
D1
D2
D3
D4
D5
D6
D7
Start Bit
8-bit Data
Stop Bit
RI
SMOD0 = X
FE
SMOD0 = 1
b. Mode 2 and 3
RXD
D0
D1
D2
D3
D4
D5
D6
D7
D8
Start bit
9-bit data
Stop bit
RI
SMOD0 = 0
RI
SMOD0 = 1
FE
SMOD0 = 1
177
4341D–MP3–04/05
