3
Simple and safe measurements using a variety of HIOKI current sensors
Ideal for Motor Evaluation and Analysis
5
6
• Choice of sensors include easy-to-measure AC and AC/DC clamp-on
sensors and feed-through current sensors for high-accuracy measurements
• Current sensor design allows for safe and efficient testing
• Use of the
(or
) allows torque
9793
MOTOR TESTING OPTION 9791
meter output and rotation input, and facilitates motor power measurement
• Immune to in-phase noise effects when measuring inverters
HTTP server function available with free dedicated PC software
Waveform Output and 16 Channel D/A output
7
8
• HTTP server function through web browser allows easy remote operation
• Free dedicated PC application can be downloaded from the HIOKI website
Collect data and operate the 3390 remotely by connecting it to a PC via
LAN or USB
• Use the
to update data every 50ms and
D/A OUTPUT OPTION 9792
output up to 16 items in analog format
• Also output the voltage and current
waveforms for each channel
(using 1 to 8 channels)
Measured waveform at 60 Hz
(Waveforms are output at 500 kS/s and sinusoidal
waveforms can be represented accurately at up to
20 kHz)
Waveform output
D/A output waveform
Multiple 3390 units can be linked for synchronized operation
9
• Connect up to four
s and synchronize their clocks and measurement
3390
timing for multiple-channel measurements
Connection Cable
(using the SYNC terminal and
)
9683
• Use dedicated application software to conduct synchronized operations
for up to 4 units and obtain all the measurement data
Connect an External Printer or Thermometer
11
• Print measurements on site by connecting the
(option)
Printer 9670
Perfectly sized for Portability and System Installation
10
•
Data from temperature measurements taken with an external
• Compact and lightweight
Ideal for field measurements
• Designed for rack mounts
thermometer aids in motor evaluation
Connecting the 3440 SeriesTemperature HiTESTER (via the RS-232C interface) also
allows temperature data to be collected simultaneously
9670
3440 Series
