AOZ1282CI
Tape and Reel Dimensions, SOT23-6
Tape
P1
D1
P2
T
E1
E2
E
B0
D0
K0
A0
P0
Feeding Direction
Unit: mm
Package
SOT-23
A0
B0
K0
D0
D1
E
E1
E2
P0
P1
P2
T
3.15
0.10
3.27
0.10
1.34
0.10
1.10
0.01
1.50
0.10
8.00
0.20
1.75
0.10
3.50
0.05
4.00
0.10
4.00
0.10
2.00
0.10
0.25
0.05
Reel
W1
S
G
N
K
M
V
R
H
W
Unit: mm
Tape Size
8 mm
Reel Size
M
N
W
W1
H
K
S
G
R
V
ø180
ø180.00
0.50
ø60.50
Min.
9.00
0.30
11.40
ø13.00
10.60 2.00 ø9.00 5.00
0.50
18.00
1.0 +0.50 / -0.20
Leader/Trailer and Orientation
Leader Tape
500mm min. or
125 Empty Pockets
Trailer Tape
300mm min. or
75 Empty Pockets
Components Tape
Orientation in Pocket
