Micro-D with Integrated EMI Backshell
Amphenol
Aerospace
Examples
1.435 MAX
1.215
.351 MAX
1.600
GROUNDING SCREW
AND WASHER
STRANDED WIRE
OR CABLE
STRAIN RELIEF
THUMBSCREW
SLOT HEAD
(2 PLCS)
.519
SOLDER CUP
OR CRIMP
AVAILABLE
MICRO-D
COVER
.362 DIA.
SHELL SIZE 51 SHOWN
(CONSULT AMPHENOL AEROSPACE FOR
OTHER SIZES OR INSERT PATTERNS)
MICRO-D SHELL
SIGNAL CONTACTS
POWER / COAX CONTACTS
Features
Material & Finishes
Aluminum alloy
• Easy assembly
Material:
• All-in-one Micro-D connector and EMI backshell
• Eliminate the use of retaining clip (E-clip) hardware
• Built in strain relief
(consult Amphenol Aerospace for zinc alloy)
Electroless nickel
Finish:
Hardware: Stainless steel
• Grounding screw and washer included
• Solder cup and wire termination available
• Sizes 9 thru 100 available
• Standard MIL-DTL-83513 insert pattern or custom
insert pattern available
Performance Information
• D.W.V. 600 VAC (at sea level)
• Insulation resistance: 5000 megaohms min.
• Signal / Power / Coaxial contacts available
• Consult Amphenol Aerospace for angled cable exit or
specific cable diameter requirement
• Temperature rating: -55 deg C to +125 deg C (+85 deg C for zinc alloy)
• Designed to meet MIL-DTL-83513 performance standards
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
