Standard Hardware
Amphenol
Aerospace
Qualiꢇied to M83513/05
MATING
FACE
9-69
100
RETAINING CLIP
(E-CLIP)
SHELL SIZE
LOW PROFILE
JACKSCREW ASSEMBLY
HM05-05
M5
HM05-02
M2
HM05-15
M5
HM05-12
M2
AMPHENOL P/N
CTHREAD
P/N CODE
M83513/05-05 M83513/05-02 M83513/05-15 M83513/05-12
(SLOT ) (ALLEN) (SLOT) (ALLEN)
.258/.235 (6.55/5.97)
MIL-SPEC P/N
A
D
.287 .005 (7.29 0.13)
.187 (4.75)
Dim. A
Dim. B
.125 (3.18)
#2-56 UNC-2A
#4-40 UNC-2A
.098 (2.49)
Dim. C (THREAD)
Dim. D
.103/.070 (2.62/1.78)
B
DIA.
N/A
Dim. E (HEX)
MATING
FACE
HIGH PROFILE
JACKSCREW ASSEMBLY
RETAINING CLIP
(E-CLIP)
9-69
100
SHELL SIZE
AMPHENOL P/N
P/N CODE
HM05-06
M6
HM05-03
M3
HM05-16
M6
HM05-13
M3
CTHREAD
M83513/05-06 M83513/05-03 M83513/05-16 M83513/05-13
(SLOT) (ALLEN) (SLOT) (ALLEN)
.258/.235 (6.55/5.97)
MIL-SPEC P/N
Dim. A
.287 .005 (7.29 0.13)
.187 (4.75)
A
.125 (3.18)
Dim. B
#2-56 UNC-2A
#4-40 UNC-2A
Dim. C (THREAD)
Dim. D
N/A
Dim. E (HEX)
.610 (15.49)
.452 (11.48)
RETAINING CLIP DETAIL
ALLEN HEAD DETAIL
SLOT HEAD DETAIL
REF .051 (#2-56)
REF .094 (#4-40)
REF .031
B
DIA.
REF .155 (#2-56)
REF .230 (#4-40)
.062 (1.57) HEX
.051 MIN (#2-56)
.062 MIN (#4-40)
HEX OR SLOT
REF .010 (#2-56)
REF .015 (#4-40)
MATING
FACE
E
DTHREAD
9-69
100
SHELL SIZE
AMPHENOL P/N
P/N CODE
JACKPOST ASSEMBLY
HM05-07
HM05-17
B
P
A
M83513/05-07 M83513/05-17
MIL-SPEC P/N
.475 .025
(12.07 0.64)
.190/.185
(4.83/4.70)
.155 (3.94)
.185/.180
(4.70/4.58)
.170 (4.32)
Dim. A
LOCK
WASHER
Dim. B
Dim. C (THREAD)
Dim. D
#2-56 UNC-2A #4-40 UNC-2A
#2-56 UNC-2B #4-40 UNC-2B
NUT
.125 (3.18)
.187 (4.75)
Dim. E (HEX)
CTHREAD
NUT DETAIL
LOCKWASHER DETAIL
.157 MAX (#2-56)
.190 MAX (#4-40)
.200 MAX (#2-56)
.270 MAX (#4-40)
.065 MAX
.019 MAX
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
