AC CHARACTERISTICS
Read-Only Operations
Parameter
Speed Options
JEDE
C
Std. Description
Test Setup
90R 100R 100 110R 110 120R 120 Unit
tAVAV tRC Read Cycle Time (Note 1)
tAVQV tACC Address to Output Delay
tELQV tCE Chip Enable to Output Delay
Min
90
100
100
100
30
110
110
110
120
120
120
ns
ns
ns
ns
ns
ns
CE#,
OE# = VIL
Max 90
OE# = VIL Max 90
Max 25
tPAC
Page Access Time
30
30
40
40
30
30
40
40
C
tGLQV tOE Output Enable to Output Delay
Max 25
30
Chip Enable to Output High Z
tEHQZ tDF
(Note 1)
Max
25
25
Output Enable to Output High Z
tGHQZ tDF
(Note 1)
Max
Min
ns
ns
Output Hold Time From
tAXQX tOH Addresses, CE# or OE#,
Whichever Occurs First
0
Read
Min
Min
0
ns
ns
Output Enable
tOEH Hold Time (Note
Toggle and
Data# Polling
10
1)
Notes:
1. Not 100% tested.
2. See Figure 12 and Table 15 for test specifications.
tRC
Addresses Stable
Addresses
tACC
CE#
tRH
tRH
tDF
tOE
OE#
tOEH
WE#
tCE
tOH
Output Valid
HIGH Z
HIGH Z
Outputs
RESET#
RY/BY#
0 V
Figure 14. Read Operation Timings
