TEST CONDITIONS
Table 15. Test Specifications
Test Condition All Speeds
Output Load 1 TTL gate
3.3 V
Unit
2.7 kΩ
Device
Under
Test
Output Load Capacitance, CL
(including jig capacitance)
30
pF
Input Rise and Fall Times
Input Pulse Levels
5
ns
V
C
L
6.2 kΩ
0.0–3.0
Input timing measurement
reference levels
1.5
1.5
V
V
Output timing measurement
reference levels
Note: Diodes are IN3064 or equivalent
Figure 12. Test Setup
KEY TO SWITCHING WAVEFORMS
WAVEFORM
INPUTS
OUTPUTS
Steady
Changing from H to L
Changing from L to H
Don’t Care, Any Change Permitted
Does Not Apply
Changing, State Unknown
Center Line is High Impedance State (High Z)
3.0 V
0.0 V
1.5 V
1.5 V
Input
Measurement Level
Output
Figure 13. Input Waveforms and
Measurement Levels
40
